Brewhouse System
Craftmaster Stainless brewhouses come in multi-vessel, three-vessel, two-vessel, and custom brewhouse configurations. We offer larger free standing and skid mount systems in sizes ranging from 1 bbl to 60 bbl.
10 BBL COMBINED MASHTUN / LAUTER TUN
COMBINED MASHTUN / LAUTER TUN FEATURES
Material: SS304 Stainless Steel
Steam Jacket Optional for Step Mashing
Inner Shell Thickness: 3mm, Cladding Thickness 2mm, Jacket Thickness 1.5mm
Inner Surface welds ground to Ra 0.6μm
Top fittings: 16” glass manway with Etched Engraved customer logo
2” 360 Degree Rotating CIP Ball
Sparge Ring
LED Interior light
2HP SEW Rake/Plow Motor with VFD control
Grist Hydrator and Sight Glass with Hot/Cold liquor blending
Side fittings: Thermowell, Spent Grain removal port
Bottom fittings: drain, Wort outlets, Wedge-wire false bottom, Wort collection header, Under flush Nozzles
10 BBL Combined Kettle / Whirlpool Tank
Combined Kettle / Whirlpool Tank
Material: SS304 Stainless Steel
Steam, Direct Fire, and Electric available per your request
Inner Shell Thickness 3mm, Cladding Thickness 2mm
Inner Surface welds ground to Ra 0.6μm
Top fittings: 16” glass manway with Etched Engraved customer logo
2” 360 Degree Rotating CIP Ball
Large 8” Condensation stack
Condensation Trap
8” butterfly valve on condensation stack for making Kettle sours
LED Interior light
Side fittings: Thermowell, Graduated Sight tube, Chimney, Inspection Door on Direct Fire units,
Tangential whirlpool inlet
4” Burner Flange Mount (For Direct Fire Units only)
Bottom fittings: Wort draw-off, drain, Combustion chamber on Direct Fire units
